Allen-Bradley SMC-50 User Manual

112 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Chapter 4 Programming
Table 22 - Communications Group Parameters
Table 23 - Utility Group Parameters
Option Module
Configuration
Basic Configuration using the HIM
When you plug an Option Module into one of the three available ports (07, 08,
or 09), you may need to configure the option module parameters. These
parameters reside in the option module through one of the ports (07, 08, or 09)
and are not included in the SMC-50 (Port <00>) parameter list.
Perform the following steps to access the option module parameters using the
HIM.
One Digitial I/O card (150-SM4) is always required for MV applications, and it
is always inserted in Slot 7.
1. Press the FOLDERS single function key.
Communications File Group Parameters
Communications Masks
(BA)
Data Links (BA)
Logic Mask Data In A1 Data Out A1
Logic Mask Act Data In A2 Data Out A2
Write Mask Cfg Data In B1 Data Out B1
Write Mask Act Data In B2 Data Out B2
Port Mask Act Data In C1 Data Out C1
Data In C2 Data Out C2
Data In D1 Data Out D1
Data In D2 Data Out D2
Utility File Group Parameters
Preferences Motor Data Expansion (MBA)
Language (BA) Motor Connection (MBA) Expansion A Configuration
Fan Configuration (BA) Line Voltage (BA) Expansion A Configuration
Motor Configuration (BA) Motor FLC (BA) Expansion A Configuration
Parameter Management (A) Rated Torque (BA)
Rated Speed (Ba)
User CT Ratio (A)
Factory CT Ratio (A)
Voltage Ratio (A)
Parameter Management (A)
TIP Before proceeding with these steps: Take note of the SMC-50 control
module port number (07, 08, or 09) that the option module is connected to.
