Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 71
Commissioning Procedure Chapter 3
• Verify that circuit board plug connectors are installed and fully inserted in
their sockets.
• Verify that the cooling fan (if supplied) is secured and the rotor is not
obstructed.
• Complete device resistance checks per user manual (refer to
Resistance
Checks on page 80 of Chapter 3).
• Complete Power Supply Tests (refer to
Power Supply Tests on page 77 of
Chapter 3).
• Program the module with correct parameter settings.
• Start the unit and record scope waveforms (line voltage, motor voltage and
motor current).
Preliminary Check
A. Verify correct power cable phase sequencing, and that connections are
tight.
B. Verify power fuse ratings and condition.
C. Verify control fuse ratings and condition.
D. Check that power cable installation has not damaged components, and
that electrical spacings have not been reduced.
E. Check that fiber-optic cables are fully seated in their connectors.
F. Check that circuit board plug connectors are installed and fully inserted in
their sockets.
G. Check that the cooling fan (if supplied) is secured and the rotor is not
obstructed.
H. Verify integrity and operation of all interlocks.
I. In the case of the 1503E, verify wiring and perform all tests in conjunction
with OEM documentation.
ATTENTION: Ensure that all sources of power are isolated and locked out before
working on installed equipment. Verify that all circuits are voltage free using a
hot stick or appropriate voltage measuring device. Failure to do so may result in
severe burns, injury or death.
