Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 143

Communications Chapter 7

Table 53 - Parameter 153 - 168 DataLinks Detail

Updating Firmware

You can obtain the latest version of firmware and instructions for the SMC-50

control module can be obtained from http://ab.rockwellautomation.com/

Motor-Control/LV-Soft-Starters/SMC-50#resources.

Parameter Number Description Min/Max [Default] Access Units

153 Data In A1 [0]-Max Parameter Number

(1)

(1) The data transferred via the DataLink function is the setting (content(s)) of the parameter number as entered by you here.

R/W —

154 A2 —

155 B1 —

156 B2 —

157 C1 —

158 C2 —

159 D1 —

160 D2 —

161 Data Out A1 —

162 A2 —

163 B1 —

164 B2 —

165 C1 —

166 C2 —

167 D1 —

168 D2 —
