Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 199
Appendix A
Parameter Information
Parameter List
Parameter Page
SMC-50 Parameters 199
150-SM2 Option Card Parameters 232
150-SM4 Parameters 234
Table 66 - SMC -50 Parameter List
Number Name Unit Min/Max Default Enum Text Description R/W
1 Volts Phase PP Ave Volt 0/15000 0 Displays the calculated average voltage of the applied three
phase to phase line voltages being measured by the SMC-50.
R
2 Volts A-B Volts 0/15000 0 Displays the Phase A to Phase B voltage applied to the SMC at
the supply terminals.
R
3 Volts B-C Volts 0/15000 0 Displays the Phase B to Phase C voltage applied to the SMC at
the supply terminals.
R
4 Volts C-A Volts 0/15000 0 Displays the Phase C to Phase A voltage applied to the SMC at
the supply terminals.
R
5 Current Phase Ave Amps 0/15000 0 Displays the average of the three phase currents flowing
through the SMC Power section to the load.
R
6 Current Phase A Amps 0/15000 0 Displays the Current flowing through the Phase A power pole of
the SMC Power section to the load.
R
7 Current Phase B Amps 0/15000 0 Displays the Current flowing through the Phase B power pole of
the SMC Power section to the load.
R
8 Current Phase C Amps 0/15000 0 Displays the Current flowing through the Phase C power pole of
the SMC Power section to the load.
R
9 Torque % -50/300 0.0 Displays the true electromechanical torque calculated based on
current and voltage feedback. In order for this reading to
display correctly the value for Rated Torque parameter must be
set.
R
10 Real Power MW -1000/1000 0.000 Displays the total Real Power. R
11 Real Energy MWH -1000/1000 0.000 Displays the Real Energy, where Real Energy equal to Real
Power X Time. This parameter is updated every 1/10 of an hour
(6 minutes).
R
12 Elapsed Time Hours 0/50000 0.0 Displays the elapsed motor running time since the last reset of
the Elapsed timer by the user.
R
13 Elapsed Time 2 Hours 0/50000 0.0 Displays the elapsed motor running time since the control
module was manufactured.
R
