Allen-Bradley SMC-50 User Manual

234 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Appendix A Parameter Information
Table 68 - 150-SM4 Parameters
Number Name Unit Min/Max Default Enum Text Description Read/
Write
SM4.01
(DIO)
Module Status 0/256 0 Ready
Input 1
Input 2
Input 3
Input 4
Aux 1
Aux 2
Aux 3
Bit 8-15 Spare
Displays information about the operational status of the 150-
SM4 Digital I/O Option Module.
Ready
: Bit 0 = Ready; Bit Set = indicates the module is ready
for operation.
Input1
: Bit 1 = Input 1; Bit Set (1) indicates the input is ON.
Input2: Bit 2 = Input 2; Bit Set (1) indicates the input is ON.
Input3
: Bit 3 = Input 3; Bit Set (1) indicates the input is ON.
Input4: Bit 4 = Input 4; Bit Set (1) indicates the input is ON.
Aux1: Bit 5 = Aux 1; Bit Set (1) indicates the auxiliary relay
output is ON.
Aux2
: Bit 6 = Aux 2; Bit Set (1) indicates the auxiliary relay
output is ON.
Aux3: Bit 7 = Aux 3; Bit Set (1) indicates the auxiliary relay
output is ON.
R
SM4.02
(DIO)
Input 1 0/13 0 [Disable]
Start
Coast
Stop Option
Start/Coast
Start/Stop
Reserved
Dual Ramp
OL Select
Fault
Fault NC
Clear Fault
Emerg Run
Reserved
Allows the user to select the operation of Input Terminal A1,
Option Input 1 on the 150-SM4 Digital I/O Option Module.
Disable
: Disable the input - ignores any assertion to Input 1,
Terminal A1.
Start: Initiates a start as set up by the start parameters at Input
1, Terminal A1 (High).
Coast
: Initiates a coast stop.- no current to motor at Input 1,
Terminal A1 (Low).
Stop Option: Initiates a stop maneuver as set up by the
stopping parameters at Input 1 (Low).
[Start/Coast]: if Input 1 = 0 - Stops motor; 1- Initiates a start
as set up by the start parameters
Start/Stop
: if Input 1 = 0- Initiates a stop maneuver as set up
by stopping parameters; 1- Initiates a start as set up by the start
parameters
Dual Ramp: if Input 1 = 0 - Use starting mode 1; 1 - Use
starting mode 2
OL Select: if Input 1 = 0 - Use Motor Overload Class 1; 1 - Use
Motor Overload Class 2
Fault
: A fault condition forced if Input 1= 1.
Fault NC: A fault condition forced if Input 1 = 0.
Clear Fault: Clear a fault from input 1 Terminal A1 (High).
Emerg Run
: Allow motor to run in emergency run mode if
asserted from Input 1, Terminal A1 - does not start motor
(High).
R/W
