86 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Chapter 4 Programming
Figure 42 - PROPERTIES Folder Screen
To modify the default password, perform the following steps using the 20-HIM-
A6 or 20-HIM-C6S:
1. From the initial power-up screen, press the FOLDERS single function key.
2. Use the forward or back arrow key until the PROPERTIES folder screen is
displayed, as shown in Figure 42
.
3. Select the CHANGE PASSWORD option, then press the Enter (#5) key.
4. Enter a numeric password, then press the Enter (#5) key. This will load the
password into the SMC-50 control module’s memory.
Parameter Access Level Modification Using the HIM
The SMC-50 control module provides three different parameter access levels:
Monitor, Basic, and Advanced. These access levels let you limit user access and/or
speed viewing or changing of certain parameters.
To view/modify the current access level, perform the following steps using the
20-HIM-A6:
1. From the initial power-up screen, press the FOLDERS single function key.
2. Press the forward or back arrow key until the DEV PARAM folder screen
appears.
TIP If the default password (0=default) is modified, ensure the modified
password is written down in a secure place. There is no way to reset the
password if it is forgotten. For additional information on password
modification, see the 20-HIM-A6 user manual, publication 20HIM-UM001
.
TIP • The access level is not maintained if power to the module is cycled.
• The default access level is Basic.
• The advanced level provides access to all parameters.
• Individual parameter access levels are shown in Table 19
through
Table 23
beginning on page 109 and is also contained in the Parameter
Linear List, Table 27
through Table 31 beginning on page 123.
PROPERTIES
Change Password
Select Language
Set Proc Display
Set Date and Time
AUTO
F
00
Stopped
0 Amps
Allen-Bradley
ESC
PROPERTIES
To Next Page
