Programming Chapter 4
Parameter File-Group
Structure
The five parameter File-Groups are structured as shown below. The access levels
for each parameter are abbreviated as follows:
•M—Monitoring,
•B—Basic,
• A—Advanced, and
• MBA—Monitoring, Basic, and Advanced.
Table 19 - Monitoring Group
Monitoring File Group Parameters
Metering Basic
(MBA)
Metering
Volts (MBA)
Metering
Current
(MBA)
Metering Power (MBA) Start Stats (MBA)
Monitoring
(MBA)
Power Quality
(MBA)
Volts P-P Ave Volts P-P Ave Current Ave Real Power Apparent Power Start Time 1 Elapsed Time THD Va
Volts P-N Ave Volts Phase A-
B
Current Phase A Real Power A Apparent Power A Start Time 2 Elapsed Time 2 THD Vb
Current Average Volts Phase B-
C
Current Phase B Real Power B Apparent Power B Start Time 3 Running Time THD Vc
Torque Volts Phase C-
A
Current Phase C Real Power C Apparent Power C Start Time 4 Energy Savings THD Vave
Motor Speed Volts P-N Ave Current Imbal Real Demand Apparent Demand Start Time 5 Motor Therm Usage THD Ia
Power Factor Volts Phase A-
N
Max Real Demand Max Apparent Demand Peak Current 1 Time to OL Trip THD Ib
Real Power Volts Phase B-
N
Reactive Power Power Factor Peak Current 2 Time to OL Reset THD Ic
Reactive Power Volts Phase C-
N
Reactive Power A Power Factor A Peak Current 3 Time to PM THD Iave
Apparent Power Volts Unbal
Reactive Power B Power Factor B Peak Current 4 Starts to PM
Real Energy Reactive Power C Power Factor C Peak Current 5 Total Starts
Reactive Energy + Reactive Demand Product Status
Reactive Energy - Max Reactive Demand
Apparent Energy
Meter Reset
