54 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019

Chapter 2 Installation

Bulletin 1560F

Refer to Figure 31 to Figure 33 to make power connection for a 1560F unit

(depending on the rating of the unit).

• Make line connections to the line connection terminals

• Make load connections to the current transformer terminals

TIP The CT assembly can be oriented to allow either top or bottom load cable exit.
