Allen-Bradley SMC-50 User Manual

Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 59
Installation Chapter 2
Figure 33 - Power Connections • 1560F – 600A, 2400…6900V (Not available in an Arc-resistant
design)
Voltage Sensing Module
Bypass Vacuum Contactor
Phase 1
Line Connections
Phase 1
Power Stack Assembly
Phase 2
Power Stack Assembly
Phase 3
Power Stack Assembly
Phase 2
Line Connections
Phase 3
Line Connections
Load Connections
(top exit shown)
Phase 1 (front)
through 3 (back)
Current Transformers
IMPORTANT For retrofit units (Bulletin 1560F), the CEC and NEC require that branch-circuit
protection of the AC line input to the controller be provided by a circuit breaker
or motor starter. This function is included with a Bulletin 1562F controller.
