Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 125
Metering Chapter 5
Power Factor
Power Factor is calculated for each phase along with a total power factor value.
The power factor calculation does not apply during Braking operations.
Table 30 - Metering Parameters Associated with Power Factor
Elapsed Time
The SMC-50 control module keeps a log of the total accumulated hours the
controlled motor has been running via the Elapsed Time metering parameter.
The Elapsed Time meter value is updated every 10 minutes and stored at power
down (accurate to 1/6 of an hour). The Elapsed Time meter accumulates to
50,000 hours of operation and can be reset to zero via the Meter Reset parameter
(see Resetting Metering Parameters
on page 122).
Elapsed Time 2 is similar to Elapsed Time. Elapsed Time 2 differs in that you
cannot reset it and will count up to 50,000 hours and then hold that value (it will
not roll over).
Table 31 - Metering Parameters Associated with Elapsed Time
283 Apparent Power A ±1000.000 0.000 R MVA
284 Apparent Power B
285 Apparent Power C
286 Apparent Power
287 Apparent Energy MVAH
288 Apparent Demand MVA
289 Max. Apparent Demand
290 Demand Period 1…255 1 R/W min
291 Number of Periods 1…15 1 R/W —
Parameter Number Name/Description Min/Max Value Default Value Access Units
292 Power Factor A -1.00…1.00 0.00 R NA
293 Power Factor B
294 Power Factor C
17 Power Factor
Parameter Number Name/Description Min/Max
Value
Default Value Access Units
12 Elapsed Time 0.0…50000.0 0.0 R Hours
13 Elapsed Time 2 R
Table 29 - Metering Parameters Associated with Power (Continued)
Parameter Number Name/Description Min/Max Value Default Value Access Units
