Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 49
Chapter 2
Installation
Receiving
It is the responsibility of the user to thoroughly inspect the equipment before
accepting the shipment from the freight company. Check the item(s) received
against the purchase order. If any items are damaged, it is the responsibility of the
user not to accept delivery until the freight agent has noted the damage on the
freight bill. Should any concealed damage be found during unpacking, it is again
the responsibility of the user to notify the freight agent. The shipping container
must be left intact and the freight agent should be requested to make a visual
inspection of the equipment.
Safety and Codes
ATTENTION: Perform the installation duties correctly. Errors may cause
commissioning delays, equipment damage, or personal injury.
IMPORTANT For the 1503E, refer to applicable documentation from OEM installation,
grounding, interlocking and wiring. This manual should be utilized in
conjunction with the OEM supplied documentation, and is suitable for
commissioning, programming, calibration, metering, serial communications,
diagnostics, troubleshooting, and maintenance of a standard solid-state
controller.
ATTENTION: The Canadian Electrical Code (CEC), National Electrical Code (NEC),
or other local codes outline provisions for safely installing electrical equipment.
Installation MUST comply with specifications regarding wire type, conductor
sizes, branch circuit protection, interlocking and disconnect devices. Failure to
do so may result in personal injury and/or equipment damage.
