Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019 105
Programming Chapter 4
Dual Ramp Start with Stop
Thecontroller lets you select between two start profiles. Configure Start Profile 1
using the Basic parameter set as explained in the previous sections. You can access
the basic parameter set with the HIM (see Table 11 on page 96
).
(4) You can also program a start delay time to delay starting for a period of time after the initiation of the START command. You can access the Start Delay parameter from the Group Starting selection. See
Table 1 1
.
(5) Any auxiliary output configured for Aux Control using the AuxX Config parameter is under control of its associated bit from the Aux Control, Parameter 180. See Parameter 180 information for bit
assignments. NOTE: This function enables forcing an output, ON or OFF.
ATTENTION: For Overload Protection, it is critical that you enter the data into
the SMC-50 control module as it appears on the motor nameplate.
TIP The Stop mode selected in the Basic parameter set will apply to both start
profiles.
The Basic parameter set provides the method to select between the
operation of Start Profile 1 and Start Profile 2 by configuration of Input 1 or
Input 2 to the Dual Ramp. If the input configured for Dual Ramp is open
(low), Start Profile 1 is selected. If the input is closed (high), Profile 2 is
selected.
