58 Rockwell Automation Publication 1560F-UM001A-EN-P - June 2019
Chapter 2 Installation
Figure 32 - Power Connections • 1560F – 180/360A, 5500…6900V (Not available in an Arc-
resistant design)
Voltage Sensing Module
Bypass Vacuum Contactor
Phase 1
Line Connections
Phase 1
Power Stack Assembly
Phase 2
Power Stack Assembly
Phase 3
Power Stack Assembly
Phase 2
Line Connections
Phase 3
Line Connections
Load Connections
(top exit shown)
Phase 1 (front)
through 3 (back)
Current Transformers
