Sequoia Series 127
1
st
Byte
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
0
0
0
0
0
0
AMP2B_PRS
AMP2A_PRS
2
nd
Byte
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
0
0
0
0
AMP1C_PRS
AMP1B_PRS
AMP1A_PRS
AMP2C_PRS
SYSTem:CMODual:Status? 1|2|3|4|all
In Binary mode, the query returns 2x8 bits word represent the modules status for 1U and 2U chassis.
It returns 4x8 bits in the 4U chassis. The parameter 1 through 6 represent the chassis address or ALL
to return all chassis in the system.
Query Syntax SYSTem:CMOD:STAT? 1
Parameters 1|2|3|4|all
Returned Paramters <NR1>[,NR1]
Example SYST:CMOD:STAT?
1
st
Byte
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
0
0
0
0
OTEMP_P
0
AMP2B_P
AMP2A_P
2
nd
Byte
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
INV_OV
HVBUS_OV
K2OFF_P
HVBUS_UV_P
AMP1C_P
AMP1B_P
AMP1A_P
AMP2C_P
SYSTem:CMODual:TEMPerature[:VALue]? 1|2|3|4|5|6|all
Only ASCII mode response is supported. This command will return the temparture fault of the
moules that are present in the system in this format: AC3 = <data>, AC2 = <data>, AC1=
<data>,DC2 = <data>,DC1 = <data>,PFC1 = <data>.
