60 Sequoia Series
MEASure:CURRent:HARMonic:PHASe?
FETCh:CURRent:HARMonic:PHASe?
Phase Selectable
These queries return the phase angle of the Nth harmonic of output current, referenced to the positive
zero crossing of the fundamental component.
The parameter is the desired harmonic number. Queries sent with a value of 0 return the dc
component. A value of 1 returns the fundamental output frequency. Harmonic orders can be queried
up to the fundamental measurement bandwidth of the measurement system:
10.4 microseconds for single-phase mode and 31.2 microseconds for three-phase mode.
Thus, the maximum harmonic that can be measured is dependent on the output frequency. Any
harmonics that represent frequencies greater than above frequencies are returned as 0.
Query Syntax MEASure[:SCALar]:CURRent:HARMonic:PHASe?<NRf>
FETCh[:SCALar]:CURRent:HARMonic:PHASe?<NRf>
Parameters 0 to 50
Examples MEAS:CURR:HARM:PHAS? 3 FETC:CURR:HARM:PHAS? 1
Returned Parameters <NR2>
Related Commands INST:NSEL
MEASure:CURRent:HARMonic:THD? ]
FETCh:CURRent:HARMonic:THD?
Phase Selectable
These queries return the percentage of total harmonic distortion and noise in the output current.
Query Syntax MEASure[:SCALar]:CURRent:HARMonic:THD?
FETCh[:SCALar]:CURRent:HARMonic:THD?
Parameters None
Examples MEAS:CURR:HARM:THD? FETC:CURR:HARM:THD?
Returned Parameters <NR2>
Related Commands INST:NSEL
