Sequoia Series 59
MEASure:CURRent:CREStfactor?
FETCh:CURRent:CREStfactor?
Phase Selectable
These queries return the output current crest factor. This is the ratio of peak output current to rms
output current.
Query Syntax MEASure[:SCALar]:CURRent:CREStfactor?
FETCh[:SCALar]:CURRent:CREStfactor?
Parameters None
Examples MEAS:CURR:CRES? FETC:CURR:CRES?
Returned Parameters <NR2>
Related Commands INST:NSEL
MEASure:CURRent:HARMonic?
FETCh:CURRent:HARMonic?
Phase Selectable
These queries return the rms amplitude of the Nth harmonic of output current. The parameter is the
desired harmonic number. Queries sent with a value of 0 return the dc component. A value of 1 returns
the fundamental output frequency. Harmonic frequencies can be queried up to the fundamental
measurement bandwidth of the measurement system:
10.4 microseconds for single-phase mode and 31.2 microseconds for three-phase mode.
Thus, the maximum harmonic that can be measured is dependent on the output frequency. Any
harmonics that represent frequencies greater than above frequencies are returned as 0.
Query Syntax MEASure[:SCALar]:CURRent:HARMonic[:AMPLitude]?<NRf>
FETCh[:SCALar]:CURRent:HARMonic[:AMPLitude]?<NRf>
Parameters 0 to 50
Examples MEAS:CURR:HARM? 3
FETC:CURR:HARM? 1
Returned Parameters <NR2>
Related Commands INST:NSEL
