86 Sequoia Series
REGenerate:UNDer[:VOLTage]
This command will set or query the under voltage limit over which the EUT is allowed to operate.
Command Syntax REGenerative:UNDer[:VOLTage] <NRf+>
Parameters 0 to max value for selected voltage range
Examples REGenerative:UNDer[:VOLTage] 10
Query Syntax REGenerative:UNDer[:VOLTage]?
Returned Parameters <NRf+>
Related Commands REG:UNDER?MIN, REG:UNDER?MAX
REGenerate:OVER[:VOLTage]
This command will set or query the over voltage limit over which the EUT is allowed to operate.
Command Syntax REGenerative:OVER[:VOLTage] <NRf+>
Parameters 0 to max value for selected voltage range
Examples REGenerative:OVER[:VOLTage] 10
Query Syntax REGenerative:OVER[:VOLTage]?
Returned Parameters <NRf+>
Related Commands REG:OVER?MIN, REG:OVER?MAX
REGenerate:DEViate:FREQuency[:SHUTdown]
This command will set or query the frequency shift used to shut down the inverter under test. Available
setting range is 0.0 to 5.0 Hz. If the frequency deviation is set to 0.0 Hz, no frequency shift will be
asserted. If set to a value other than zero hertz, the frequency shift will be applied when the fed back
current exceeds the programmed current limit for more than the delay set by the REG:DEL:FREQ
command.
Command Syntax REGenerative:DEViate:FREQuency[:SHUTdown] <NRf+>
Parameters 0 to 5
Examples REGenerative:DEViate:FREQuency[:SHUTdown] 2.5
Query Syntax REGenerative:DEViate:FREQuency[:SHUTdown]?
Returned Parameters <NRf+>
Related Commands REG:DEV:FREQ?MIN, REG:DEV:FREQ?MAX
REGenerate:DELay:FREQuency[:SHUTdown]
This command will set the delay in seconds before applying the programmed frequency
deviation in an attempt to shut down the inverter under test. Available setting range is 0.25 to
10.0 seconds. If the frequency deviation is set to 0.0 Hz, no frequency shift will be asserted.
If set to a value other than zero hertz, the frequency shift will be applied when the fed back
current exceeds the programmed current limit for more than the delay set by the REG:DEL:FREQ
command.
.Command Syntax REGenerative:DELay:FREQuency[:SHUTdown] <NRf+>
Parameters 0.25 to 10, time in seconds.
Examples REGenerative:DELay:FREQuency[:SHUTdown] 10
Query Syntax REGenerative:DELay:FREQuency[:SHUTdown]?
Returned Parameters <NRf+>
Related Commands REG:DEL:FREQ?MIN, REG:DEL:FREQ?MAX
