8 Rev. 2
Introduction
Model 1700 System Specifications
Controller output power: 2 A
AC
at line voltage
Autofill start/stop triggering: Level-based; 0% to 100%, adjustable
Fill Timeout Period: 1 minute to 99 hours, 59 minutes
Fill error alarm: Fill time out
Communication Protocol
Host computer network protocol: 10Base-T TCP/IP and RS-232 115,200 baud
IP Addressing: DHCP or static, IPv4
Network connectivity
and traffic indication:
Link and Activity LEDs on instrument rear panel
RS-232 connector specifications: 9-pin D-sub female connector to connect standard
DTE 9-pin D-sub male connector using a standard
straight cable
Communication command set: SCPI-based. 100% backward compatible with the
Model 184, 185, 186 instruments.
Power Requirements
Primary: 100-240 ±10% V
AC
, 50-60 Hz, 2.2 A maximum
(200 VA plus sum of controller output)
Backup battery for RTC: CR2032
Physical
Dimensions
b
:
Table top configuration:
3.8” H x 8.4” W x 11.4” D
[97 mm H x 213 mm W x 290 mm D]
Single rack mount configuration: 3.5” H x 19.0” W
x 11.4” D
[89 mm H x 483 mm W x 290 mm D]
Weight: table-top configuration: 3.3 lbm [1.5 kG];
single rack-mount configuration: 4.0 lbm [1.8 kG]
Environmental Limits
Ambient Temperature: Operating: 0°C to 40°C
[32°F to 104°F];
Non-operating: -20 °C to 60 °C
[-4 °F to 140 °F]
Relative Humidity: 0 to 95%; non-condensing
Maximum Instrument Background
Field:
Gauss (TBD)
Standards
Test Standards Testing of Equipment for Measurement, Control,
and Laboratory Use (IEC 61326-1:2012, EN 61326-
1)
Electrostatic Discharge (ESD) (EN 61000-4-2)
Radiated Immunity (EN 61000-4-3)
Fast Transient Burst (EN 61000-4-4)
Surges (EN 61000-4-5)
Conducted Immunity (EN 61000-4-6)
