AMI 1700 - Completing Closed Dewar Calibration

Rev. 2 37
4Calibration
Model 1700 instrument is calibrated at the factory for a specific length
sensor(s) for use in a specific liquid(s). The calibration length(s) and
calibration liquid(s) are listed on the calibration sticker on the bottom of
the instrument. For capacitance sensors, if the factory calibration method
utilized was approximate, the calibration length will be noted as an
approximate value.
4.1 Setting the System Date and Time
1. From the home screen, choose
MENU.
2. From the MENU screen, choose
SYSTEM.
3. From the SYSTEM
CONFIGURATION, PAGE 1
screen, choose SET.
Figure 4-1. Menu Selection From Home
Screen
Figure 4-2. Menu Selection Screen
Figure 4-3. System Menu, Page 1
