AMI 1700 - Commands for Configuring Setpoints

Rev. 2 69
Remote Interface Reference
Command Set Reference : Configuring Setpoints
5.5.3 Commands for configuring setpoints
Command: CONFigure:RELAY1:CHannel <value>
Function: Assigns relay 1 to either no channel (disabled) (0), nitrogen
(1), or helium (2).
Returns: <CR><LF>
Default: 0
Command: CONFigure:RELAY2:CHannel <value>
Function: Assigns relay 1 to either no channel (disabled) (0), nitrogen
(1), or helium (2).
Returns: <CR><LF>
Default: 0
Command: CONFigure:RELAY1:OPeration <value>
Function: Configures relay №1 such that it closes (alarms) when the
level is ≤ the setpoint (0) or ≥ the setpoint (1).
Returns: <CR><LF>
Default: 1
Command: CONFigure:RELAY2:OPeration <value>
Function: Configures relay №2 such that it closes (alarms) when the
level is ≤ the setpoint (0) or ≥ the setpoint (1).
Returns: <CR><LF>
Default: 0
Command: CONFigure:FILL:CHannel <value>
Function: Assigns the auto fill control relay to either no channel
(disabled) (0), nitrogen (1), or helium (2).
Returns: <CR><LF>
Default: 0
Note: If the relay is not assigned to a channel, the units are
assumed to be percent.
Command: CONFigure:RELAY1:SETpoint <value>
Function: Configures the relay №1 trip setpoint in the current channel’s
units.
Returns: <CR><LF>
Default: 20
Note: If the relay is not assigned to a channel, the units are
assumed to be percent.
