14 Rev. 2
Installation
Setting Up an Autofill System
Note
MSDS sheets for the ECL are available upon request.
2.5 Setting Up an Autofill System
Autofill systems are useful in applications where liquid level in a dewar
must be maintained without operator intervention.
To create an autofill system, a cryogenic liquid source must be attached to
the target or level controlled dewar via a solenoid-controlled valve. The
valve will be controlled by the Model 1700 Instrument.
2.5.1 Autofill System Description
For autofill, the system consists of a Model 1700 Instrument with a liquid
level sensor, and a solenoid-operated flow valve. The instrument makes
continuous level measurements and based on level, energizes the valve to
