Channel contentsChannel contents
Use the Channel contentsChannel contents drop-down menu to select the signal transmitting
into the timeslot:
OffOff: No channel content is selected.
ToneTone: Tone with specified frequency and level.
TransparentTransparent: Received content in the same channel time slot is used.
SpeechSpeech: Pre-programmed speech sequence. 'Drop and insert' on Tx screen will
be switched to On.
Channel Time SlotChannel Time Slot
Touch the Channel Time SlotChannel Time Slot graphics and use the dialog box to select the
channel timeslot. If Speech or Tone is selected audio is inserted in selected
timeslot. If Transparent is selected, the destination for transparent errors is
selected.
ToneTone
Touch the Tone FrequencyTone Frequency field and key in the frequency, using the numeric
soft keys.
Touch the LevelLevel field and key in the level.
CAS tabCAS tab
The CASCAS tab contains the following parameters:
