33..55 Command-Based Remote ControlCommand-Based Remote Control
Using command-based scripts makes the Network Master a fully automated
measurement instrument.
The Network Master remote control functions support the built-in Ethernet
service interface. Ethernet connectors of test interface do not support remote
control functions.
Software specifications are in conformity with the IEEE488.2 standard and
SCPI version 1999 (Standard Commands for Programmable Instruments).
All commands are described in a separate document:
MT1000A/MT1100A/MT1040A Remote Scripting Operation Manual (M-
W4041AE).
This icon on Status bar indicates whether the Network Master is controlled by
the command-based scripts or not. If touching this icon, buttons appear.
Touching the Turn OffTurn Off button will disconnect the SCPI connection. Use this
button if disconnecting the Ethernet cable.
Touching the Enable Local ControlEnable Local Control button will allow the panel operation with
keeping SCPI connection. This function is useful for debugging the control
software.
