55..22 SONET Setup and StatusSONET Setup and Status
An OC-xx/STS-xxOC-xx/STS-xx button in the navigation area of the Ports SetupPorts Setup screen gives
you access to the SONET setup for the transmitter and/or receiver of the
currently selected port.
Refer to SDH/SONET switching for switching to SONET.
Synchronous Optical Networking (SONET) refers to a standardized protocol that
transfers digital signals over optical fiber using lasers. At low transmission rates
data can also be transferred via an electrical interface.
The electrical interface is available when the MU100010A is installed.
The SONET interface uses the optical ports.
MU104011A, MU104014A Connector PanelMU104011A, MU104014A Connector Panel
MU104015A Connector PanelMU104015A Connector Panel
