5555 Framework core communication port, fixed. Used by Control
Software main GUI, including the Remote Upgrade function.
5650 to
5699
Application servers, fixed range. Used by Control Software
Application GUIs.
5898 Unit reset port, fixed. Used by Control Software Remote Reset
function.
58012 Remote wake-up port, fixed. Used by Control Software Remote
Wake Up function.
In addition, the following ports are used for controlling the Network Master
with a method other than using the Control Software:
56001
(default)
SCPI server port, user configurable. Used by remote SCPI
clients. Refer to Remote Control section for details how to setup.
5900
(default)
VNC (TCP), user configurable. Used by remote VNC clients.
5800
(default)
VNC over HTTP, user configurable. Used by remote VNC over
HTTP tunnel clients.
Refer to VNC section for details how to setup VNC
communication ports.
135, 137,
138, 139,
445
File Sharing, fixed ports.
33..44..44 Starting Control SoftwareStarting Control Software
1. Open Anritsu-MX100001A folder from Start menu.
2. Click MX100001A-V*.**-RemoteMX100001A-V*.**-Remote.
If Windows Security Alert appeared, click Allow accessAllow access.
Before connecting to the Network Master, confirm that the response from the Network
Master is quick enough. If the response from the Network Master via the Ethernet
network is too late, a connection fails and the message "Network connection is too
slow!" appears.
Executing Remote Operation on control PC:
1. If Control Software launched, the initial screen for remote operation appears
as below.
To Next Page
