33..44 Remote OperationRemote Operation
With the MX100001A MT1000A/MT1100A/MT1040A Control Software
(hereafter, "Control Software") application installed, your PC is capable of
supporting remote access to the Network Master. Control Software simulates
the panel operation of the Network Master, allowing you to operate and view
results on a PC through a LAN or Internet connection. If more Network Masters
are linked to a network, they can be remotely controlled by the same PC, one at
a time.
The recommended time to control the Network Master from the Control
Software is up to 48 hours. If you leave your PC for a longer period of this time,
Please close the Control Software once.
The Network Master measurement will continue after that, so if you start the
Control Software again, it will return to the original state.
If the Control Software is connected to the Network Master for more than 48
hours, the Control Software may terminate abnormally. In this case as well, if
you start the Control Software again, it will return to the original state.
33..44..11 Installation of Control SoftwareInstallation of Control Software
Operation EnvironmentOperation Environment
OS Windows 7/8.1/10 English/Japanese
Interface Ethernet 100BASE-TX/1000BASE-T
Display 800 × 600 dots or more
1. Copy the installer stored in the Network Master to your PC, by USB flash drive
or the file sharing function.
File Name: MX100001A-Setup-x.xx-xxxxx.exe
"x"s in the file name mean numerics showing the version.
2. Double click the installer file.
3. If User Account Control dialog box appears, click YesYes.
4. After the installation finishes, click CloseClose.
Click StartStart > All Programs > Anritsu > MX100001A folder. Confirm that
following programs appear. "V*.**" is replaced to the version name.
MX100001A-V*.**-Editor
MX100001A-V*.**-Remote
MX100001A-V*.**-Viewer
V*.**-Uninstall
When installing a new version of the Control Software, previous versions are not
automatically uninstalled. To manually uninstall a Control Software version, execute
"Uninstall" from the Control Software folder from the Start menu of Windows.
33..44..22 Connection and SetupConnection and Setup
To make Remote Operation application communicate with the Network Master:
