33..33 Connector PanelConnector Panel
All connections (both for
test interfaces
and for
service interfaces
) are placed
on the connector panel of the Network Master.
CAUTIONCAUTION
Do not seal holes on the connector panel.
Doing so causes temperature in the module high and the Network Master may
stop its operation.
33..33..11 Test InterfacesTest Interfaces
The connectors used for testing are placed on the module.
