22..55 Support Stand and Support Stand and HandleHandle
22..55..11 Support StandSupport Stand
The Network Master is equipped with a support stand keeping the instrument at
a convenient angle during the operation. To extract the stand: pull out the
metal bar on bottom and rear of the Network Master - it automatically stays in
the correct position.
Be sure to open a support stand fully. Otherwise, the Network Master will be
more likely to tip over. Moreover, the air flow on bottom panel will be
insufficient.
Support stand on the rear panel
It is recommended to use the support stand on the rear panel for the one
module configuration and the two modules configuration described in 2.6
"Modules Configuration".
Support stand on the bottom panel
It is recommended to use the support stand on the bottom panel for the three
modules configuration and the four modules configuration described in 2.6
"Modules Configuration".
Using the support stand on the bottom panel for the one module configuration can tip
over the equipment and may be damaged.
