2. Select the software file. When you select the folder where you unpacked the
installer, the installer file will be selected automatically. Multiple files can be
selected by selecting a file while holding down the CtrlCtrl key.
3. Progress bar shows Upload Progress. Clicking CancelCancel aborts the file
uploading.
4. After file uploading finishes, click Start InstallationStart Installation.
Clicking Start InstallationStart Installation will reboot the Network Master. You cannot remotely connect
to the Network Master during installation.
You cannot remotely check the installation progress. Installation takes about 10
minutes.
33..44..66 Remote Power ControlRemote Power Control
Power OnPower On
If the Network Master is in Stand-by mode, it is possible to remotely get the
unit into the Operation state.
1. Click StartStart > All Programs > Anritsu > MX100001A folder.
2. Click MX100001A-V*.**-RemoteMX100001A-V*.**-Remote.
3. On the Control Software startup screen, enter the IP address of the Network
Master in the Remote Unit IP AddressRemote Unit IP Address field.
4. Click StartStart in Wake UpWake Up tab.
5. After the progress bar reaches 100%, click OKOK in the dialog box.
Power OffPower Off
If the Allow remote PC shutdownAllow remote PC shutdown check box is selected in the Remote Control
dialog box, you can remotely set the Network Master in Stand-by mode.
1. In the upper-right corner of the MX100001A window, click the Close button.
2. Click Shut DownShut Down.
33..44..77 Remote ResetRemote Reset
The Remote Reset function can be helpful if the unit is on a remote site and
unexpectedly freezes or becomes unresponsive. The possibility to remotely
reset an instrument can be disabled by unchecking the Enable Remote ResetEnable Remote Reset
check box in the Remote Control options.
To remotely force a reboot the Network Master, specify the Network Master
using its serial number.
1. On the Control Software startup screen, enter the IP address of the Network
Master in the Remote Unit IP AddressRemote Unit IP Address field.
2. Enter the serial number in the Controller SNController SN field on the ResetReset tab.
3. Click StartStart on the ResetReset tab.
