4. After the progress bar reaches 100%, click OKOK in the dialog box.
Make sure to save measurements and settings before initiating Remote Reset function.
The Reset will force the Network Master to reboot. All unsaved or ongoing
measurements will be lost.
33..44..88 Stand-alone EditorStand-alone Editor
MX100001A Editor allows users to load, edit, and save Setup files of any
possible Network Master configuration, without connecting to an actual
instrument.
1. Click StartStart > All Programs > Anritsu > MX100001A folder.
2. Click MX100001A-V*.**-EditorMX100001A-V*.**-Editor.
3. Set configuration of the Network Master by clicking options in SelectSelect
ControllerController, and Add Module(s)Add Module(s).
To save the configuration, click Save ConfigurationSave Configuration.
4. Click OKOK. After a while, the GUI of the selected Network Master configuration
appears.
5. Select an application on Application Selector. Then, select port resources.
6. After the application screen has appeared, select configure settings and
measurement parameters.
7. Once done, save the setup file by clicking Load/SaveLoad/Save on Application Toolbar.
Load the Setup File (saved file at step 7 above) saved by the MX100001A
Editor on the Network Master by clicking Load/SaveLoad/Save button on the Application
Toolbar. Alternatively, import the settings file as a Favorite, and launch the new
application from the Favorites screen on the Application SelectorApplication Selector.
