Alarms/Errors/Alarms/Errors/
OthersOthers
IconIcon PCM descriptionPCM description
Flags detected in currently selected signaling channel
Channel activity
Touching ResetReset button will clear icons.
Audio levelAudio level
Two dBm meters show the volume of the currently selected audio channel
(Port1 - Port2).
55..33..44 Errors/Alarms InsertionErrors/Alarms Insertion
This section describes the errors or alarms insertion for the PDH layer on the
Application toolbar.
Select the port to insert errors, and the stimuli type. The settings items vary
depending on the selected stimulus type.
PDH Alarm/ErrorsPDH Alarm/Errors: Inserts errors or alarms related the PDH multi frame or
the pattern error.
PDH frequencyPDH frequency: Adds the frequency offset to the PDH bit rate.
55..33..44..11 PDH Alarms/ErrorsPDH Alarms/Errors
1. Select Error insertionError insertion or AlarmAlarm using the drop down menu.
Alarm will be inserted continuously.
No errorNo error: Turns off inserting Alarms or Errors.
ManualManual: Inserts errors in the specified counts if you touch the Error
Insert icon.
Burst*1E-03Burst*1E-03 to Burst*1E-07Burst*1E-07: Inserts errors of burst length in the
specified rate continuously. For example, Error burst lengthError burst length is set to 5
and Burst*1E-06Burst*1E-06 is selected, the errors will be inserted in five straight
frames per one million frames. The Error Insert icon shows only status.
ESES: Inserts one or more errors in one second (Errored Second). Insert
icon shows only status.
