Physical StatusPhysical Status
Interface StatusInterface Status
Monitor ButtonsMonitor Buttons
66..11..33 Status InformationStatus Information
This section describes the status information available in the status area of the
Ethernet ports setup screen.
66..11..33..11 Status SummaryStatus Summary
The status summary displayed for the Ethernet interface consists of the
following information:
The actual summary information displayed depends on the type of the Ethernet
interface.
The topmost part of the status area gives you access to information about the
current physical status of the selected interface. A summary consisting of the
most relevant status indicators is displayed constantly. By touching the
summary, you can launch a display that contains the detailed status
information.
The second part of the status area gives you access to alarm and error
information for the selected interface. The status is indicated by the lamp color.
You can choose whether to view only the current alarm and error status, or to
view all alarms and errors in the alarm trap since it was last reset.
A summary consisting of the most relevant alarm/error indications is displayed
constantly. By touching the summary, you can launch a display that contains
all alarms/errors.
At the bottom of the status area are the following buttons that give you access
to various monitor information. By touching a button, you can launch the
corresponding information display.
SyncESyncE
IEEE 1588v2IEEE 1588v2
OAMOAM
OH CaptureOH Capture
Frame CaptureFrame Capture
TransceiverTransceiver
