Line codeLine code
Use the Line codeLine code radio buttons to select transmission line code.
AMIAMI: Alternate Mark Inversion
B8ZSB8ZS: Bipolar Eight Zero Substitution
PCM framePCM frame
Use the PCM framePCM frame radio buttons to enable (OnOn) or disable (OffOff) insertion of
PCM frame in the transmitted signal.
When PCM frame is set to Off, many of the following transmitter parameters are
insignificant.
Frame typeFrame type
Use the Frame typeFrame type radio buttons to select the relevant frame type: J1J1, ESFESF or
SF/D4SF/D4.
Contents tabContents tab
The ContentsContents tab contains the following parameters:
