55..55..11..22 E3 Signal SetupE3 Signal Setup
Touching the transmitter's E3E3 button in the navigation area will display the
screen shown below.
To make the Port 2 transmitter follow the Port 1 transmitter (i.e. copy its
settings) when using Port 1 and Port 2, touch the drop-down menu in the
navigation area and select the Tx1Tx1. The Port 2 settings continue to follow the
Port 1 transmitter change. The default setting is NoneNone. Note that the Port 1
transmitter cannot follow the Port 2 transmitter.
PCM framePCM frame
Use the PCM framePCM frame radio buttons to enable (OnOn) or disable (OffOff) insertion of
PCM frame in the transmitted signal.
Pattern typePattern type
Select the pattern to be inserted in the transmitted signal. Available patterns are
the same as the transmitter setup. Refer to Pattern type in "E1 Setup and
Status". Available patterns are:
OffOff
User [32] bitUser [32] bit, User [2048] bitUser [2048] bit
PRBS 9PRBS 9 to PRBS 31PRBS 31
Fox PatternFox Pattern, Fox (CMA3000)Fox (CMA3000)
All 0'sAll 0's, All 1'sAll 1's
Alternating 1:1Alternating 1:1, Alternating 1:3Alternating 1:3, Alternating 1:7Alternating 1:7, Alternating 3:24Alternating 3:24
Touch 'Normal' or 'Inverse' pattern type.
Touching the 'ITU standard' button will apply ITU-T O.150 recommended
Pattern typePattern type for 34 Mbit data rates (PRBS 23 Inverse).
User patternUser pattern
User pattern field is enabled if Pattern type is set to User [32] bitUser [32] bit or User [2084]User [2084]
bitbit. Touch the User patternUser pattern field and use the launched Pattern EditorPattern Editor dialog box
to define the user pattern. Depending on the selected pattern type, different
user pattern setup options will be available.
