Unicast SearchUnicast Search
When Any IP address (Unicast search)Any IP address (Unicast search) is set at Search Type, set the IP address
range of unicast. The IP address changes continuously.
Search Target CountSearch Target Count: Set the number of IP addresses to search.
Search Target IPSearch Target IP: Set the starting IP address. The ending IP address is
displayed at right hand of the field.
66..1313..33 Test ResultsTest Results
Perform DiscoveryPerform Discovery
Touching this icon on the Application tool bar starts the processing for discovering
Network Masters.
66..1313..33..11 SummarySummary
The following screen is displayed to check the test results of the Ethernet
Discovery application.
In this screen, up to 16 results of searching for Network Masters are displayed.
If password is set to the Network Master, an icon appears in LockLock row.
Selecting a line by touching the table enables button operation.
DetailDetail
Touching this button displays the detailed information.
Application changeApplication change
Touching this button opens the dialog box to change the application running in
Network Master.
UpdateUpdate
Touching this button updates the Current ApplicationCurrent Application row in the table.
