APS/PCCAPS/PCC
STATSTAT Signal typeSignal type
000000 Reserved
001001 Normal path signal
010010 Reserved
011011 Reserved
100100 Reserved
101101 ODUk-LCK
110110 ODUk-OCI
111111 ODUk-AIS
APS/PCC has four bytes. Requests/Status is defined for First byte. The request
or status is shown in bits 1-4.
The protection type is shown in bit 5-8.
OTN ApplicationsOTN Applications
