CATIONCATION
Be careful not to bump the guide pins (8, 9, 11 and 12) against the connectors
(7 and 10).
When attaching the module, make sure the four corners are aligned.
Failure to do so can cause damage to the connectors.
5. Tighten the four screws.
After the module attachment has finished, the external appearance will be as
below.
