99..33..33..44 LatencyLatency
A screen similar to Throughput is displayed by touching LatencyLatency in the
Navigation area.
This screen displays the result of Latency test.
The latency and measured jitter are shown in bar charts.
The following items are displayed in the result table.
Step: Step numbers in Throughput test
Fr size: Frame size defined in Control screen
Frames: Number of sent frames
Frame rate: Number of frames sent per second
Util: Utilization in percent
Load: Number of bits sent per second
Act Load / Tput: Number of frames received per second
This is a measured throughput.
Latency: Delay time of frames
Jitter: Latency time variation
99..33..33..55 BurstBurst
A screen similar to Throughput is displayed by touching BurstBurst in the
Navigation area.
This screen displays the result of Burst test.
The maximum burst length is shown in a bar chart.
The following items are displayed in the result table.
Step: Step numbers in Throughput test
Fr size: Frame size defined in Control screen
Frames: Number of sent frames
Burst size: Number of frames per Burst
Back Pressure: Utilization in percent
Frames lost: Difference between sent frame count and received frame count
99..33..33..66 CreditCredit
A screen similar to Throughput is displayed by touching CreditCredit in the
Navigation area.
This screen displays the result of Credit test.
The measured throughput is shown in a bar chart.
The following items are displayed in the result table.
Step: Step numbers in Throughput test
Fr size: Frame size defined in Control screen
Credit Size: Sent value of BB credit count
Frame rate: Number of frames sent per second
Util: Utilization in percent
Load: Number of bits sent per second
