SimultaneousSimultaneous
measurement portsmeasurement ports
Port Status LEDPort Status LED
Frequency variableFrequency variable
rangerange
Electrical OutputElectrical Output
1GFC: 1.0625 Gbit/s SFP
2GFC: 2.125 Gbit/s SFP
4GFC: 4.25 Gbit/s SFP
8GFC: 8.5 Gbit/s SFP+
10GFC: 10.51875 Gbit/s SFP+
16GFC: 14.025 Gbit/s SFP+
CPRI1: 614.4 Mbit/s SFP
CPRI2: 1228.8 Mbit/s SFP
CPRI3: 2457.6 Mbit/s SFP
CPRI4: 3072.0 Mbit/s SFP
CPRI5: 4915.2 Mbit/s SFP+
CPRI6: 6144.0 Mbit/s SFP+
CPRI7: 9830.4 Mbit/s SFP+
CPRI8: 10137.6 Mbit/s SFP+
CPRI9: 12165.12 Mbit/s SFP+
CPRI10: 24330.24 Mbit/s SFP28
OBSAI 1x: 768 Mbit/s SFP
OBSAI 2x: 1536 Mbit/s SFP
OBSAI 4x: 3072 Mbit/s SFP
OBSAI 8x: 6144 Mbit/s SFP+
Simultaneous measurement using two ports is available.
(Available for QSFP28, QSFP+, SFP28, SFP, SFP+, or RJ45 interface.
For QSFP-DD and QSFP56, using two ports is not available.)
Yellow Link
Green: Activity (flashing)
Range *: Relative to Bit Rate: −200ppm to + 200ppm, 0.1ppm step
Performance is not guaranteed when the frequency is out of the optical
module's specification.
Sync Clock Output Divided clock output synchronized with QSFP-
DD/QSFP56/QSFP28/SFP28 transmit data
Only the port 1 is supported.
Frequency *
100GbE/25GbE:
OTU4:
200GbE/400GbE:
Divided 1/8 or 1/16 from Lane Bit rate:
3.22265 GHz (1/8), 1.61133 GHz (1/16)
3.49406 GHz (1/8), 1.74703 GHz (1/16)
Divided 1/8 or 1/16 from Lane Baudrate:
3.32031 GHz (1/8), 1.66016 GHz (1/16)
Level 350 mVp-p min.
900 mVp-p max.
Connector SMA female
Termination 50 Ω, AC coupling, single-end
