Dummy channelDummy channel
handlinghandling
Test patternsTest patterns
Preset dataPreset data
Tandem connectionTandem connection
Frequency OffsetFrequency Offset
Alarm InsertionAlarm Insertion
Error InsertionError Insertion
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-4 - VC-4 - TU-12 - VC-12 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-12 - VC-12 - E1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-11 - VC-11 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-4 - VC-4 - TU-11 - VC-11 - DS1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - DS3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - E3
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - TU-12 - VC-12 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-3 - VC-3 - TU-12 - VC-12 - E1 (Async/Sync)
STM-64/STM-16/STM-4/STM-1/STM-1e - AU-3 - VC-3 - TU-11 - VC-11 - Bulk
STM-64/STM-16/STM-4/STM-1/STM-1e
- AU-3 - VC-3 - TU-11 - VC-11 - DS1 (Async/Sync)
Copy, Unequipped (For AU only)
PRBS: 2
9
−1, 2
11
−1, 2
15
−1, 2
20
−1, 2
23
−1, 2
29
−1,2
31
−1 (Normal/Inverse)
Fixed :User Pattern, All0, All1, Alternating 1:1, Alternating 1:3, Alternating
1:7, 2 in 8
User Pattern : 32 bits, 2048 bits
OH Preset data
SOH : All bytes except B1, B2, H1, H2 and H3 byte
VC-4/VC-3 POH : All bytes except B3
VC-12/VC-11 POH : All bytes except BIP-2
Path trace Setting: J0, J1, J2 (ASCII data, 16 bytes/64 bytes)
Off, N1(VC-4), N1(VC-3), N2(VC-12), N2(VC-11)
±200 ppm 0.1 ppm step
Item
LOS, LOF, OOF, MS-AIS, MS-RDI, AU-AIS, AU-LOP, HP-TIM, HP-PLM, HP-
UNEQ, HP-RDI, TU-AIS, TU-LOP, TU-LOM, LP-TIM, LP-UNEQ, LP-RDI, LP-
PLM, LSS, TC-UNEQ, TC-LTC, TC-TIM, TC-AIS, TC-RDI, TC-ODI
Insertion :
Permanent, Alternate (Excluding LOS, OOF and LSS)
Permanent (For LOS, OOF and LSS)
Alternate :
Alarm length : 1 to 8000 (Frame)
Normal length : 1 to 8000 (Frame)
Item
A1A2, B1, B2, MS-REI, B3, HP-REI, V5/B3, LP-REI, TC-IEC, TC-REI, TC-OEI,
TC-BIP-2, ERR-TRANS, Pattern error
