Delay measurementDelay measurement
SDH PerformanceSDH Performance
MeasurementMeasurement
Tributary ScanTributary Scan
SONET MappingsSONET Mappings
APS Protocol analyze
APS configuration :Ring or Linear
Ring : Short Path, Long Path
Linear : 1+1 architecture, 1:n architecture
APS Protocol Request : The value of K1, K2 byte is sent depending on selected
type.
APS Interpretation : Number, Elapsed Time
Measurement Mode : Single, Repeat
Measurement Period : 0.5, 1, 2, 5, 10 s
Measurement Range : Up to 10 000 000.000 μs / resolution 0.1 μs, Timeout
Setup : G826, G.828+G.829, M.2101.1(M2100)
Allocation
Mux Allocation 0 to 100%
VC-4 Allocation 0 to 100%
VC-3 Allocation 0 to 100%
VC-11/VC-12 Allocation 0 to 100%
Time period : 15minutes, 1hour, 2hour, 24hour, 7days (only M.2101.1)
Result : ES, SES, BBE, UNAV
Display : Count, Ratio
Displays the alarm status of all channels in a specified layer.
Green (No alarm), Red (Alarm occurring), Gray (Not applied)
1212..55..22..22 SONETSONET
OC-192 - STS-192c - STS-192c SPE - Bulk
OC-192/OC-48 - STS-48c - STS-48c SPE - Bulk
OC-192/OC-48/OC-12 - STS-12c - STS-12c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - E4
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-3c - STS-3c SPE - TU-3 - VC-3 - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-3c - STS-3c SPE - VT-11 - VT-11 SPE - DS1 (Async/Sync)
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - DS3
OC-192/OC-48/OC-12/OC-3/STS-3 - STS-1 - STS-1 SPE - E3
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - Bulk
OC-192/OC-48/OC-12/OC-3/STS-3
- STS-1 - STS-1 SPE - VT-12 - VT-12 SPE - E1 (Async/Sync)
