Error PerformanceError Performance
ResultResult
Frame FormatFrame Format
Transmitter ClockTransmitter Clock
Through modeThrough mode
MappingMapping
for G.826
Display : Count, Ration
G.821/G.826/M.2100 analysis of the received signal
Status
Current information on:
Alarms and errors
Input level indication
Actual bit rate
Frequency deviation
E1: CAS bits, FAS/non FAS bits
DS1: CAS bits, F-Bit, S-Bit
DS3: F-bits
Round trip delay
APS switching time (Only available in case of E1 or DS1.)
1212..55..33 OTNOTN
1212..55..33..11 OTN SetupOTN Setup
OTU4, OTU3, OTU3e1, OTU3e2, OTU2, OTU1e, OTU2e, OTU1f, OTU2f, OTU1
Reference Clock
Internal clock
External clock
BITS
SETS
2MHz
10MHz
GPS
Received
Transparent, OH Overwrite Thr. (ALL OTU/ODU/OPU OH)
OTU4 (Client PRBS)
OTU4-ODU4/OPU4-PRBS
OTU4-ODU4/OPU4-ODTU4.1-ODU0/OPU0-PRBS
OTU4-ODU4/OPU4-ODTU4.2-ODU1/OPU1-PRBS
OTU4-ODU4/OPU4-ODTU4.2-ODU1/OPU1-ODTU01-ODU0/OPU0-PRBS
OTU4-ODU4/OPU4-ODTU4.8(ODU2)-ODU2/OPU2-PRBS
OTU4-ODU4/OPU4-ODTU4.8(ODU2)-ODU2/OPU2-ODTU2.1
-ODU0/OPU0-PRBS
OTU4-ODU4/OPU4-ODTU4.8(ODU2)-ODU2/OPU2
-ODTU12(PT=20,21)-ODU1/OPU1-PRBS
OTU4-ODU4/OPU4-ODTU4.8(ODU2)-ODU2/OPU2
-ODTU12(PT=20,21)-ODU1/OPU1-ODTU01-ODU0/OPU0-PRBS
OTU4-ODU4/OPU4-ODTU4.8(ODU2e)-ODU2e/OPU2e-PRBS
OTU4 (Client Null)
SpecificationsSpecifications
