SpecificationsSpecifications
1212..66 Optical ModulesOptical Modules
Correct functionality can only be guaranteed with optical modules purchased from
Anritsu for the MU104011A, MU104014A, and MU104015A .
Safety measures for laser productsSafety measures for laser products
Optical modules for the MU104011A, MU104014A and MU104015A comply
with optical safety standards in IEC 60825-1.
Specification of optical modules purchased from Anritsu for the MU104011A,
MU104014A, and MU104015A (each with 1 transmitter and 1 receiver) with
LC connectors (subject to change without further notice):
Order No./ NameOrder No./ Name
Description Description
(Approx. Distance)(Approx. Distance)
Min. InputMin. Input
SensitivitySensitivity
InputInput
WavelengthWavelength
OutputOutput
PowerPower
OutputOutput
WavelengthWavelength
G0315A
10G LR/LW 1310 nm SFP+
10GBASE - LR 1310 nm
Single mode (10 km)
-14.4 dBm
1260 to
1565 nm
-6 to -1
dBm
1290 to
1330 nm
G0316A
10G ER/EW 1550 nm 40 km
SFP+
10GBASE - ER 1550 nm
Single mode (40 km)
-15.8 dBm
1260 to
1565 nm
-3 to 3
dBm
1530 to
1560 nm
G0318A
10G ZR/ZW 1550 nm 80 km
SFP+
10GBASE - ER 1550 nm
Single mode (80 km)
-22 dBm
1260 to
1565 nm
0 to 5
dBm
1525 to
1565 nm
G0319A
Up to 2.7G 1310 nm 15 km SFP
STM-1/-4/-16 short haul,
1310 nm (15 km)
-18 dBm
1270 to
1580 nm
-5 to 0
dBm
1260 to
1360 nm
G0320A
Up to 2.7G 1310 nm 40 km SFP
STM-1/-4/-16 long haul,
1310 nm (40 km)
-27 dBm
1270 to
1580 nm
-2 to 3
dBm
1280 to
1335 nm
G0321A
Up to 2.7G 1550 nm 80 km SFP
STM-1/-4/-16 long haul,
1550 nm (80 km)
-28 dBm
1270 to
1580 nm
-2 to 3
dBm
1500 to
1580 nm
G0322A
1G/2G/4G FC 1310 nm SFP
1GFC, 2GFC, 4GFC
1310 nm (10 km)
-18 dBm
1260 to
1360 nm
-8 to 0
dBm
1260 to
1360 nm
G0323A
1G/2G/4G FC 1550 nm SFP
1GFC, 2GFC, 4GFC
1550 nm (40 km)
-18 dBm
1470 to
1600 nm
0 to 5
dBm
1510 to
1590 nm
G0328A
1G/2G/4G FC 850 nm SFP
1GFC, 2GFC, 4GFC
850 nm (0.5 km)
-15 dBm
830 to 860
nm
-9 to 0
dBm
830 to 860
nm
G0329A
10G LR 1310 nm SFP+
10GBASE - LR 1310 nm
Single mode (10 km)
-14 dBm
1260 to
1355 nm
-8.2 to 0.5
dBm
1260 to
1355 nm
G0332A
100 M FX 1310 nm MM SFP
100BASE-FX 1310 nm
Multi mode (2 km)
-31 dBm
1270 to
1600 nm
-20 to -15
dBm
1280 to
1380 nm
G0333A
10G SR/SW 850 nm SFP+
10GBASE - SR 850 nm
Multi mode (0.3 km)
-11.1 dBm
840 to 860
nm
-7.3 to -1
dBm
840 to 860
nm
Order No./ NameOrder No./ Name
Description Description
(Approx. Distance)(Approx. Distance)
Min. InputMin. Input
SensitivitySensitivity
InputInput
WavelengthWavelength
OutputOutput
PowerPower
OutputOutput
WavelengthWavelength
G0356A
8G FC/10G SR 850 nm SFP+
8G FC/10G SR 850 nm SFP+ -11.1 dBm
840 to 860
nm
-8.2 to -1
dBm
840 to 860
nm
