Anthos A3 Plus - Electromagnetic Compatibility

A3 PLUS - A5 - A6 PLUS - L6
SURGICAL SINGLE CART
EN
103
SURGICAL
SINGLE
CART
1580x780x1130(h)
Dental chair packaging
dimensions:
A3 PLUS
A5
A6 PLUS
1520x730x1030(h)
L6
1520x730x1030(h)
Packed dental unit weight:
A3 PLUS
A5
140 kg
A5 CART
140 + 45 kg
A5 SINGLE
CART
45 kg
A6 PLUS
140 kg
L6
150 kg
SURGICAL
SINGLE
CART
85 kg
Packed dental chair weight:
A3 PLUS
A5
A6 PLUS
130 kg
L6
130 kg
Radio module technical
specifications:
Cloud module
Type of transmission: Wi-Fi
Operation frequency band: 2412 - 2484 MHz
Maximum power: +21.5 dBm
Wireless pedal module
Type of transmission: Bluetooth®
Operation frequency band: 2402 - 2480 MHz
Maximum power: +4 dBm
FUSES
Identification
Value
Protection
Position
MAIN
Fuse
T 10 A
T 15 A
220-240 V ~: Dental unit power supply line
100-120 V ~: Dental unit power supply line
Connection box
DENTAL CHAIR
Fuse F1
T 6.3 A
220-240 V ~: Dental chair power supply line.
Connection card
DENTAL CHAIR (INVERTER)
Fuse F1
Fuse F2
T 6.3 A
T 8 A
T 10 A
220-240 V ~: Inverter power supply line
100-120 V ~: Inverter power supply line
Inverter motor
Inverter card
Inverter card
QUICK COUPLINGS
Fuse
T 2 A
220-240 V ~: Power outlet supply line
Connection box
Guidance and Manufacturer's declaration - Electromagnetic emissions
The dental unit is designed to operate in the specified electromagnetic environment. The customer or the user of this dental unit
must ensure its use in an electromagnetic environment with the following features:
Emission test
Conformity
Electromagnetic Environment
RF emissions
CISPR 11
Group 1
The dental unit uses RF energy only for its internal operation.
For this, the RF emissions are very low and do not interfere with the
electronic devices nearby.
RF emissions
CISPR 11
Class A
The dental unit must be used only by adequately trained dentists
and paramedics. The dental unit may cause radio interferences or
disturb the operation of the nearby equipment. It may be necessary
to adopt countermeasures, such as re-orienting or moving the
dental unit or shielding the installation site.
Guidance and Manufacturer's declaration - Electromagnetic immunity
The dental unit is designed to operate in the specified electromagnetic environment. The customer or the user of the dental unit
must ensure its use in an electromagnetic environment with the following features:
Immunity test
IEC 60601-1-2
Test level
Level of
conformity
Electromagnetic Environment
Electrostatic discharge
(ESD)
± 8 kV contact
± 15 kV air
IEC 60601-1-2
Test level
Floors must be made of wood, concrete or ceramic
tiles. If floors are covered with synthetic material, the
