5 Control And Monitoring
5.1 System Status
The system status of the unit can easily be monitored from the web-based user
interface. Information about the currently configured services, active alarms and
alarm history is available.
5.1.1 Service View
Expand the Status folder in the navigation pane and click the Service View icon. The
Service View will be displayed as shown in Figure 66.
Figure 66 - Service view
The information in the Service View can be sorted by clicking on the column
headers.
The Service View shows all configured services by default and the following
information is available:
Input input information about the corresponding service. The notation is
<X:Y:Z> where X is the slot position of the input module, Y is the port
on the input module and Z is the service PID.
Service the name of the service
Output output information about the corresponding service. The notation is
<X:Y:Z> where X is the output module, Y is the multicast address and Z
