SW Version 2.04 30-January-2009 Page 111 of 128
4 F-connectors for QPSK inputs
1 BNC connector for ASI Monitoring Port
10/100/1000BaseT MMI (optional)
System status LED
2 slots wide
A.4 ASI Input Module
Function: Receiving an ASI transport stream. Optional MMI interface.
3 BNC connectors for ASI input
10/100/1000BaseT for management (RJ45)
System status LED
1 slot wide
A.5 QAM Input Module
Function: Receiving a QAM modulated transport stream. Optional MMI interface.
