Appear TV SC2000 - Qpsk Input Module; Cofdm Input Module; Qam Input Module; Ip Input Module

SW Version 2.04 30-January-2009 Page 122 of 128
Error Code Alarm Level Description
Output buffer overflow.
Packet dropped.
CRITICAL Transport stream output buffer towards backplane is
overflowing. Packages are dropped.
This is can happen if the destination card is overloaded. In this
case the output card will send flow control messages to the
backplane switch telling it is not able to receive more packets,
the switch then tells the input card not to transmit packets to
the backplane. Hence if destination card is overloaded this
alarm will be triggered.
System Reference clock
failure
CRITICAL The system clock signal from the switch card is not detected
by the FPGA. The switch card may be broken.
System Clock
Unsynchronized
CRITICAL The card has detected a situation where the internal clock
needed to re-synch to the reference clock.
C.8 QPSK Input Module
Error Code Alarm Level Description
Input buffer overflow.
Packet dropped.
CRITICAL Transport stream input buffer is overflowing. Packages are
dropped.
See description for the same alarm on the ASI input card.
Output buffer overflow.
Packet dropped.
CRITICAL Transport stream output buffer towards backplane is
overflowing. Packages are dropped.
See description for the same alarm on the ASI input card.
No Lock CRITICAL No valid transport stream detected on input port
BER > 2x10
4
CRITICAL Bit Error Rate is considerable.
I2C ERROR CRITICAL Communication error with QPSK-on card. If this is a recurring
problem the card should be rebooted.
System Reference clock
failure
CRITICAL The system clock signal from the switch card is not detected
by the FPGA. The switch card may be broken.
System Clock
Unsynchronized
CRITICAL The card has detected a situation where the internal clock
needed to re-synch to the reference clock.
C.9 COFDM Input Module
Error Code Alarm Level Description
Input buffer overflow.
Packet dropped.
CRITICAL Transport stream input buffer is overflowing. Packages are
dropped.
See description for the same alarm on the ASI input card.
Output buffer overflow.
Packet dropped.
CRITICAL Transport stream output buffer towards backplane is
overflowing. Packages are dropped.
See description for the same alarm on the ASI input card.
No Lock CRITICAL No valid transport stream detected on input port
I2C ERROR CRITICAL Communication error with COFDM-on card. . If this is a
recurring problem the card should be rebooted.
System Reference clock
failure
CRITICAL The system clock signal from the switch card is not detected
by the FPGA. The switch card may be broken.
System Clock
Unsynchronized
CRITICAL The card has detected a situation where the internal clock
needed to re-synch to the reference clock.
C.10 QAM Input Module
Error Code Alarm Level Description
Input buffer overflow.
Packet dropped.
CRITICAL Transport stream input buffer is overflowing. Packages are
dropped.
See description for the same alarm on the ASI input card.
Output buffer overflow.
Packet dropped.
CRITICAL Transport stream output buffer towards backplane is
overflowing. Packages are dropped.
See description for the same alarm on the ASI input card.
No Lock CRITICAL No valid transport stream detected on input port
I2C ERROR CRITICAL Communication error with COFDM-on card. . If this is a
recurring problem the card should be rebooted.
System Reference clock
failure
CRITICAL The system clock signal from the switch card is not detected
by the FPGA. The switch card may be broken.
System Clock
Unsynchronized
CRITICAL The card has detected a situation where the internal clock
needed to re-synch to the reference clock.
C.11 IP Input Module
Error Code Alarm Level Description
