SW Version 2.04 30-January-2009 Page 120 of 128
Error Code Alarm Level Description
VBI PID Missing MAJOR No TS packed associated with this PID has been received by
the decoder the last second.
VBI-data missing MINOR VBI data is missing
Video Data Error MAJOR The decoder found errors in the decoded video.
Video Missing CRITICAL No video data in the TS packed identified by the Video PID.
Video PID Missing CRITICAL No TS packed associated with this PID has been received by
the decoder the last second.
Video PID Scrambled CRITICAL Video PID received by decoder is scrambled. Check
descrambling (CAM and Smartcard)
AFD-data missing WARNING The decoder has been configured to enable WSS-AFD, but
does not receive any WSS AFD data.
PTS synch error MAJOR PTS is out of synch
Nicam board Mismatch WARNING The decoder is configured with an option file that specifies
that a Nicam board shall be present, but no Nicam board is
detected.
RF Board mismatch MINOR The decoder is configured with an option file that specifies
that a RF board shall be present, but no RF board is
detected.
Common IF board
mismatch
MINOR The decoder is configured with an option file that specifies
that the decoder shall have Common Interface support, but
no Common Interface hardware is detected. This is not
related to the CAM itself.
SW/HW mismatch MAJOR The HW platform used by the decoder is also used for the
Descrambler and Scrambler cards. During boot an option file
is scanned which tells the card what it is. If the card is told it
is a descrambler, but detects that it is the decoder software
running then this SW/HW mismatch alarm is raised.
A2 board mismatch MINOR The decoder is configured with an option file that specifies
that a A2 board shall be present, but no A2 board is
detected
No Latens SSM MINOR Missing Latens SW
Bad backplane frame MAJOR Communication error with backplane
Switched, reason: Link
Down
INFORMATION The internal redundancy module switched to the other input
card due to a LINK DOWN condition on the backplane
Switched, reason:
Logout
INFORMATION The internal redundancy module switched to the other input
card because it lost contact with the login server on the MMI
board.
Switched, reason:
Alarm
INFORMATION The internal redundancy module switched to the other input
card due to a an alarm condition on the DDM card
Switched, reason:
Operator
INFORMATION The internal redundancy module switched to the other input
card due to a command from the user.
* UPC is short for UPCONVERTER
C.4 Radio Module
Error Code Alarm Level Description
No data input CRITICAL The Radio card does not receive any of the expected data.
Corrupt MPEG stream CRITICAL The incoming stream is corrupt
Critical buffer filling MINOR
Unsupported MPEG
stream
CRITICAL The incoming stream is of an unsupported format.
MPX build time
consumption high
MINOR
Temperature > 60 MINOR Temperature is high
Low output power CRITICAL
Testtone enabled MINOR
Switched INFORMATION The internal redundancy module has switched to the other
backplane.
C.5 Descrambler Module
Error Code Alarm Level Description
FPGA TS packet
overflow
CRITICAL Buffer overflow into the Descrambler card. Try to reduce
bitrate.
Transport stream
missing
CRITICAL Descrambler module is not receiving configured transport
stream
High Continuity Error
Rate
CRITICAL Transport stream received by descrambler module has lost
more then 18 packages during a 6 second period.
