SW Version 2.04 30-January-2009 Page 10 of 128
The High Performance Dual Decoder card replaces the Dual Decoder RF module as of
end Q4 2008, and will also be used as the up-converter module for Dual Decoder RF
with stereo sound.
3.4.6 FM Radio output
For the FM radio module, with built-in FM modulation and up-conversion to the FM
band, the FM up-converted output is a female F-connector.
Each module can offer up to eight channels. The FM output can cover the complete
band from 47 MHz to 862 MHz.
The options to enable RDS or insert RDS information, as well as enable outside
management are presented in the GUI.
The RF output can be muted by an external system by applying 5 V to the mute
connector. Muting the input mutes all channels available on the RF output connector.
The FM radio module is 1 slot wide.
