SW Version 2.04 30-January-2009 Page 77 of 128
Component Mode Select PID forwarding mode:
auto all all components are forwarded
auto a/v only audio and video
auto a/v/ttxt audio, video and teletext
Scrambler If a scrambler module is installed you can choose to
scramble the selected service by selecting one of the
available scramblers from the pull down menu
ECM If scrambling has been selected, assign the output stream
to the appropriate scrambled subscriber package. Please
refer to chapter on scrambling to set up subscriber
packages.
MPEG Packets/Frame Number of MPEG packets per UDP frame. Default is 7.
Type of Service Specifies the Type-of-Service (TOS) value to prioritize
between Delay, Throughput and Reliability. Please refer to
the IP protocol specification for details.
Time to Live Set the time-to-live (TTL) value defined for the IP
multicast protocol:
0 restricted to the same host
1 restricted to the same subnet
32 restricted to the same site
64 restricted to the same region
128 restricted to the same continent
255 unrestricted
SPTS Enabled Enable SPTS
RTP Enable Real Time Protocol
EMM Passthrough Forward CAT/EMM tables for service that are received
scrambled and not descrambled in the chassis.
Next, add an input service to the IP output. Under the Input Services heading you
will find all the available services. Just drag-and-drop the service you want to assign
to output over to the Output window and the service is assigned to the IP address
specified under Default Stream Properties. Please notice that the IP address under
the Default Stream Properties is incremented for every service you assign to the
output.
Add all required services to the IP output field (Output). Remember to adjust the
default parameters if required.
